● 32 Single-Ended or 16 Differential inputs

● Voltage Ranges: ±25mV, ±50mV, ±100mV, ±2.5V, ±5V, ±10V

● Settling Time: 9µsec to .01% (see online manual for details)

● Maximum Input Voltage without damage: 250V

● Input Impedance: 5MΩ Differential, 10MΩ Single Ended

● Common Mode Voltage: ±15V

● Temperature Scale Factor: +10mV/°K @ 25°C

● ESD Protection: up to 2000V

● Current: 4 to 20mA (factory option)

● Common Mode Rejection Ratio: Over 100dB

● Temperature Error @25°C: 1°C typical

● Channels: 1 of 7, jumper selected 8th channel is temp sensor output is used.

● Output Drive Capability: 600Ω or 10mA

● Voltage Range: ±10 (x1, x2, x100, x200 gain); ±5 (x0.5, x50)

● Slew Rate: 2V/µsec

● Power Required: +5V @ 200mA with with no load for excitation

● Interrupt Requests: none

● Gain Nonlinearity: ±0.005%

● Humidity Tolerance: 5 to 95% RH non-condensing

● Operating Temperature: 0 to 70°C, (-40 to 85°C Optional)

● Storage Temperature: -55 to +125°C

● Temperature Coefficient of Gain: Removed by Gain Calibration

● This product is designed to be in full compliance with CE requirements.
