● 12-bit resolution A/D

● Eight true differential inputs, or eight single-ended inputs optional

● Programmable input ranges of: 0-5V, 0-10V, ±5V, ±10V

● 100KHz sampling rate

● On-board pacer clock and counter timers

● Four double-buffered analog outputs

● Jumper selectable output ranges of: 0-5V, 0-10V, ±5V, ±10V

● 24 digital I/O lines, type 82C55 with change of state detect on port C, buffers on ports A & B

● Flexible configurations to suit your needs

● FACTORY OPTIONS:

- 4-20mA inputs with offset

- Channel by channel pre-amplifier gains of 1-100

- +5VDC only operation

- 0 to +70°C and -40 to +85°C versions available

- RoHS Available. Please contact us for ordering information

● Equipment monitoring

● Environmental measurements

● Embedded OEM

● Education/Laboratory

● Portable

● Industrial Automation

● Precision Measurement

● Analysis, Monitoring, and Control

ACCES also offers Custom Software Services for our products. Our prices are unbelievably low, often as inexpensive as free! If you need something tweaked to support your needs, or an entire enterprise application developed from scratch, it is definitely worth your time to inquire with us, first. A list of ACCES drivers and the files that compose them under different versions of Windows, so you can easily redistribute ACCES cards and drivers.
