● Number and Type: 32, non-polarized, optically isolated from each other and ground

● Voltage Range: 3 to 31 volts DC or AC Rms ( 40 to 10000 Hz ), CMOS compatible

● Isolation: 500V*(see manual) channel-to-ground and channel-to channel

● Input Resistance: 1.8K ohms in series with opto coupler (two LEDs)

● Response Time: 4.7 mSec w/filter, 10 µSec w/o filter (typical)

● Number of outputs: Four SPDT form C

● Contact Type: Single crossbar; Ag with Au clad

● Carry Current: 2A

● Rated Load AC: 0.5 A at 125 VAC (62.5 VA max )

● Rated Load DC: 1 A at 24 VDC ( 30 W max )

● Switch Voltage / Current: 125 VAC; 60 VDC / @ 1A (max)

● Contact Resistance: 100 mΩ max

● Max. Switching Voltage: 125 VA, 60 VDC

● Max. Switching Current: 1A

● Max. Carrying Current: 2A

● Contact Life-mechanical: 5,000,000 operations min

● Operating / Release Time: 5 ms max (mean value: approx 2.5 ms, and 0.9 ms respectively)

● Generated when inputs change state if enabled by software and jumper selected IRQ

● IRQ Sharing via tri-stated line driver on jumper selected interrupt line (positive edge true)

● +5 VDC @ 150 mA (all inputs HI & all relays ON, no load on fused 5V power)

● +5 VDC power is provided via a resettable polyfuse (at 0.5A) for application and general purpose usage

● Operating temperature: 0°C to +70°C, optionally -40°C to +85°C available

● Storage temperature: -50° to +120°C

● This product is designed to be in full compliance with CE requirements.
