● Channels: 4, 8, or 16
● Voltage: 3 to 31VDC or AC RMS (40 to 1000Hz)
● Isolation: 500V channel-to-ground and channel-to-channel (see manual)
● Response Times:
- Filtered: 4.7ms rise and fall
- Non-Filtered: 10µs rise; 30µs fall
● Channels: 4, 8, or 16
● Type: SPDT Form C
● Contact Type: Single crossbar; Ag with Au clad
● AC Load: 0.5A at 125VAC (62.5 VA max)
● DC Load: 1A at 244VCDC (30W max)
● Switching Voltage:125 VAC, 60VDC max
● Contact Resistance: 100mω max
● Contact Life: 5 million operations min
● Operating Time: 5msec max
● Release Time: 5msex max
● Ethernet 10/100 Base T, Auto-detecting, 1.5kV Isolation
● Operating Temperature Range: 0°C to 70°C (Optional -40°C to +80°C)
● Storage Temperature Range: -40°C to +85°C
● Humidity: 5%-90%, non-condensing
● Board Dimension: 3.550 x 3.775 inches
● Box Dimension: 4.00 x 4.00 x 1.7 inches
● Connectors:
- Isolated Inputs: Dual row 0.1” 34-pin
- Relay Outputs: Dual row 0.1″ 50-pin
- DC power jack: 2.0mm + center post
- Screw terminals: Available via enclosure cutout
● External AC/DC 5V regulated power is required
● 5V @ 300mA plus 30mA per energized relay;5V @ 780mA with all relays on, typical<300mA typical (no load)
