● Logic High: 2.0 to 5.0 V DC.

● Logic Low: -0.5 to +0.8 V DC.

● Input Load (Hi): 20 uA.

● Input Load (Lo): -200 uA.

● Logic High: 2.5 VDC min., source 15 mA.

● Logic Low: 0.5 VDC max., sink 24 mA. (64 mA optional)

● +5 VDC computer power. 1A fuse included on IOD-24..

● Operating Temperature Range: 0° to 60°C.

● Storage Temperature Range: -40° to +100°C.

● Humidity: 0 to 90% RH, non-condensing.

● Size: 5.0″ Long (12.7cm),

● Input: +5 VDC at 200 mA typical

● This product is designed to be in full compliance with CE requirements.
