● PCI Express

● 5 Volt:

- Input Low ≤ 1.5V, ≤2µA

- Input High ≥3.5V, ≤2µA

- Output Low ≤ 0.55V @ 32mA

- Output High ≥3.8V @ 32mA

● 3.3 Volt:

- Input Low ≤ 0.8V, ≤2µA

- Input High ≥2.0V, ≤2µA

- Output Low ≤ 0.55V @ 24mA

- Output High ≥2.4V @ 24mA

● 2.5 Volt:

- Input Low ≤ 0.7V, ≤2µA

- Input High ≥1.7V, ≤2µA

- Output Low ≤ 0.5V @ 8mA

- Output High ≥1.9V @ 8mA

● 1.8 Volt:

- Input Low ≤ 0.63V, ≤2µA

- Input High ≥1.17V, ≤2µA

- Output Low ≤ 0.45V @ 4mA

- Output High ≥1.2V @ 4mA

● Number / Type Three 82C54 programmable counters

● Counter size 16-bit

● Logic level VCCIO

● On-board clock 1MHz

● Clock Pulse Width High – 30ns (min) Low – 40ns (min)

● Operating Temperature 0° to +70°C

● Storage Temperature -40° to +105°C

● Humidity 5% to 95% RH, without condensation

● Card Dimensions Length – 6.6″; Height – 4.2″ seated

● This product is designed to be in full compliance with CE requirements.
