● PCI Express

● Lines: 24; Ports A, B, and C

● Type: Emulates 8255 compatible chips

● Logic Level: VCCIO

● Pull-up/down: 10k ohm, jumper selectable

● 5 Volt:

- Input Low ≤ 1.5V, ≤2µA

- Input High ≥3.5V, ≤2µA

- Output Low ≤ 0.55V @ 32mA

- Output High ≥3.8V @ 32mA

● 3.3 Volt:

- Input Low ≤ 0.8V, ≤2µA

- Input High ≥2.0V, ≤2µA

- Output Low ≤ 0.55V @ 24mA

- Output High ≥2.4V @ 24mA

● Operating Temperature 0° to +70°C

● Storage Temperature -40° to +105°C

● Humidity 5% to 95% RH, without condensation

● Card Dimensions Length – 6.6″; Height – 4.2″ seated

● This product is designed to be in full compliance with CE requirements.
