PCI Express Digital I/O系列产品
PCIe-DIO-48S 产品技术规格
PC Interface

● PCI Express

Digital Signaling

● VCCIO 5V (TTL), optional 3.3V (LVTTL) on 50 pin header

Digital Inputs

● Logic High 2.0V to VCCIO

● Logic Low 0V to 0.8V

● Current ±20uA (max)

Digital Ouputs

● Logic High 2.0V (min); 32mA source

● Logic Low 0.55V (max); 64mA sink

● Power Output VCCIO (P2 & P3; pin 49) Via 0.5A resettable fuse≤2µA

Environmental

● Operating Temperature 0° to +70°C

● Storage Temperature -40° to +105°C

● Humidity 5% to 95% RH, without condensation

● Card Dimensions: 4.72″ (120mm) long by 4.20″ (106.7mm) high

Regulatory Compliance

● This product is designed to be in full compliance with CE requirements.
