PCI Express Isolated Digital I/O系列产品
PCIe-IIRO-8 产品技术规格
PC Interface

● PCI Express

Isolated Digital Inputs

● Number of inputs: 8

● Type:Non-polarized, optically isolated from each other and from the computer. (not TTL/CMOS compatible)

● Voltage Range: 5 to 24V DC or AC (50 to 1000 Hz)

● Isolation: 500V*(see manual) channel to channel and channel to ground

● Input Resistance: 470 ohms in series with two diodes and an LED

● Response Time: 10 mSec w/filter, 20 uSec w/o filter

Relay Outputs

● Number of outputs: 8

● Contact Rating: 2A carry current, bifurcated, gold clad, silver palladium

● Contact Arrangement: Channels 0-4 are SPDT Form C and channels 5-7 are SPST Form A.

● Contact Rating: Initial 100 milliohms maximum

● Contact Life: mech’l: 5 million operations minimum; elect’l: 5 million operations minimum at full load

● Operating Time: 2 milliseconds maximum

● Release Time: 1 milliseconds maximum

● Regulatory Approvals: UL and CSA

Interrupts

● Interrupts enabled by software, generated when digital inputs change state

Connector

● Back Panel DB37 Male

Power Required

● +5VDC @ 0.675 A (all relays ON) for PCIe-IIRO-8

Environmental

● Operating Temperature 0° to +70°C

● Storage Temperature -40° to +105°C

● Humidity 5% to 95% RH, without condensation

● Weight: Approx. 8 oz. (227 grams)

● Size: PCIe-IIRO-8 is 6.6″ (168 mm) long

Regulatory Compliance

● This product is designed to be in full compliance with CE requirements.
