● High-speed USB 2.0 device, USB 3.0 compatible

● Two 1MHz 16-bit A/D converters for 2MHz aggregate sampling rate

● Analog and digital inputs acquired simultaneously, with timestamping

● 16 kSample FIFO (shared by all inputs)

● Per channel software selectable ranges of 0-1V, 0-2V, 0-5V, 0-10V, ±1V, ±2V, ±5V, ±10V

● Eight digital I/O’s (four inputs & four high-current outputs)

● High retention USB type B connector for vibration-proof, worry-free communications

● Alternate USB micro-fit header can be used to reduce board footprint in embedded applications

● Small rugged steel industrial enclosure

● FACTORY OPTIONS：

- OEM version (board only) features PC/104 module size and mounting compatibility

- Extended temperature (-40° to +85°C)

- External power

- Screw terminals for power input provide high retention connection

- LVTTL DIO lines

- RoHS compliant product

- Support for Wind River VxWorks (call for ordering information)

● Equipment monitoring

● Environmental measurements

● Embedded OEM

● Education/Laboratory

● Portable

● Industrial Automation

● Precision Measurement

● Analysis, Monitoring, and Control

We provide a variety of cables, terminal boards and mounting provisions such as the MP104-DIN for convenient DIN-Rail mounting.
