● High-speed USB 2.0 device

● 16 high-speed digital I/O lines feature continuous, sustained throughput up to 16 MB/s

● Capable of 80 MB/s bursts with flexible synchronous clock and handshaking capabilities

● Continuous streaming over USB with no maximum waveform length

● On-board embedded FIFO memory up to 128 kByte

● 18 additional digital I/O lines arranged in 4 programmable groups

● All outputs buffered with 24 mA sink/source capabilities

● Type B USB connector features high-retention design

● Standard 68-pin SCSI high density latching connector

● Custom high-speed function driver

● Alternate embedded USB connector

● All required power drawn from USB port, no external power adapter required

● Small, (4″ x 4″ x 1.25″) rugged industrial enclosure

● PC/104 module size and mounting compatibility

● Industrial strength and high-retention Type B USB connector

● Now with Firmware 2.0 features!

- Onboard Watchdog Timer

- Configurable power-on defaults

- Digital input debouncing and latching

- Digital output Pulse Width Modulation (PWM) and Matrix Mapping

● FACTORY OPTIONS:

- LVTTL for 3.3V applications

- Input only, output only, and input/output versions

- OEM version (board only) features PC/104 module size and mounting compatibility

- External power for high current capabilities

- Extended temperature and DIN rail mounting provisions

- RoHS available, please contact us for ordering information

- Support for Wind River VxWorks (call for ordering information)

● Testing and Debugging

● Laboratory Automation

● Manufacturing Test

● Image Capture

● Process Monitoring

● Datasource Emulation

● Embedded OEM

Available accessories include a wide variety of cables and screw terminal boards for quick and easy connectivity.
