● Number: 8

● Logic High: 2.0V (min), source 32mA

● Logic Low: 0.55V (max), sink 64mA

● Power Output: +3.3VDC via 50mA polyfuse (resetting)

● Tru-ISO: IPC-2221B

● I/O to PC:

- 1500 V peak (AC or DC)

- UL-1577

- UL recognition (pending): 5000 V rms for 1 minute

● Careful attention has been paid to isolation design, including extensive keep-out zones and hand-routed circuit paths, as well as component and material selection

● Operating Temperature 0° to +70°C, optional -40° to +85°C

● Storage Temperature -40° to +105°C

● Humidity 5% to 95% RH, without condensation

● Power required: +3.3VDC @ 500ma, +1.5VDC @ 415mA

mPCIe card characteristics

● Weight:7.2 grams

● Size: Length: 50.95mm (2.006″); Width: 30.00mm (1.181″)

● I/O connector:

- On-card: 501190-2017 20-pin latching

- Mating: Molex 501189-2010

● On-cable I/O connector

- On-cable: Female, D-Sub Miniature, 25-pin

- Mating: Male, D-Sub Miniature, 25-pin

● This product is designed to be in full compliance with CE requirements.
