● Ethernet 10/100 RJ45 connector for interfacing to CPU or network

● 48 or 24 channel high-current TTL digital I/O lines

● Compatible with industry standard I/O racks such as Grayhill, Opto 22, Western Reserve Controls, etc.

● Eight-bit ports software selectable for inputs or outputs

● All 48 digital I/O lines buffered with 32 mA source / 64mA sink current capabilities

● Jumper selectable I/O pulled up to 5V (via 10KΩ) for contact monitoring, pulled down to ground or floating

● DHCP or static IP assignment

● 5VDC regulated external power supply included

● Resettable 0.5A fused +5VDC output per I/O connector

● Standard 50-pin IDC-type shrouded connectors with key

● Small, (4″x4″x1.7″) rugged, steel industrial enclosure

● RoHS Standard

● FACTORY OPTIONS:

- Low-voltage (LVTTL) for 3.3V applications

- OEM version (board only), features PC/104 size and mounting compatibility

- Order with our IOB-48 for 48 channels of output isolation

- Extended Temperature Operation (-40°C to +85°C)

● Industrial Automation

● Embedded OEM

● Portable DAQ

● Laboratory

● Home Automation

● Kiosks

● Direct connect spring-cage terminal boards brings out all DIO signals (STB-DIO-48ETH).

● Additional accessories include flat ribbon cables and DIN-rail mountable screw terminal boards for remote wiring and installation.

● For isolated inputs and outputs, we have 2 types of accessories:

- Our low cost IIB-24 provides optically isolated inputs to any of our 50-pin connectors via one of our cables.

- Our IOB-48 has High-Side Power MOSFET outputs that mate directly to the board only (-OEM) versions of our products.

Because of Ethernet’s ubiquitous nature, these boards are supported for use in all operating systems — including Windows, Linux, Unix, iOS, Android, — even Raspberry PI, etc. The software package includes a free Linux and Windows software package with sample programs and source code in C#, Delphi, Visual Basic, and Visual C++ for Windows. Also provided is a graphical setup program in Windows and extensive ethernet-packet level API documentation. Third party application support includes a Windows standard DLL interface usable from the most popular application programs. Embedded OS support includes Windows Embedded Standard.
