● PCI Bus

● I/O Connections: Shielded male D-sub 9-pin IBM AT style connector compatible with RS422 and RS485 specifications.

● Character Length: 5,6,7, or 8 bits.

● Parity: Even, odd, or none.

● Stop Interval: 1, 1.5, or 2 bits.

● Up to 115,200 baud, Asynchronous. Faster rates, up to 460,800 baud, are achieved by jumper selection on the card. Type 16550 buffered UART.

● Receiver Input Sensitivity: +200 mV, differential input.

● Common Mode Rejection: +12V to -7V

● Drive Capability: 60 mA transmit output with thermal shutdown.

● Multipoint: Compatible with RS422 and RS485 specifications.

● Size: 6.6″ long (167.64mm) by 2.21″ tall (56.17mm) seated height.

● Operating Temperature Range: 0 to +60°C.

● Storage: -25 to +85°C

● Humidity: 0 to 90 percent (non-condensing)

● Power Required: +5VDC at 175 mA typical

● Size: 4.80" long (122mm) by 1.80" high (46 mm).

● This product is designed to be in full compliance with CE requirements.
