● PCI Bus

● I/O Connection: 9 Pin DBM Connector.

● Character length: 5, 6, 7, or 8 bits.

● Stop Interval: 1, 1.5, or 2 bits.

● Serial Data Rates: Up to 115,200 baud, asynchronous. A faster range of rates, up to 460,800, is achieved by jumper selection on the card. Type 16550 buffered UART.

● Address: Continuously mappable within 0000 to FFFF (hex) range of PCI-bus addresses.

● Receiver Input Sensitivity: +200 mV, differential input.

● Common Mode Rejection: +12V to -7V.

● Transmitter Output Drive Capability: 60 mA, with thermal shutdown.

● Operating Temperature Range: 0 to +60°C.

● Storage: -25 to +85°C

● Humidity: 0 to 90 percent (non-condensing)

● +5VDC at 50 mA typical, +12VDC at 5 mA (Quiescent), 15 mA (Maximum).

● 4.80 inches long (122 mm).

● This product is designed to be in full compliance with CE requirements.
