● PCI Bus

● Number of inputs: 16

● Type: Non-polarized, optically isolated from each other and from the computer. (not TTL/CMOS compatible)

● Voltage Range: 5 to 24V DC or AC (50 to 1000 Hz)

● Isolation: 500V*(see manual) channel to channel and channel to ground

● Input Resistance: 470 ohms in series with two diodes and an LED

● Response Time: 10 mSec w/filter, 20 uSec w/o filter

● Number of outputs: 16 (PCI-IIRO-16)

● Contact Rating: 2A carry current, bifurcated, gold clad, silver palladium

● Contact Arrangement:

- Channels 0-4 are SPDT Form C

- Channels 5-7 are SPST Form A

- Channels 8-12 are SPDT Form C

- Channels 13-15 are SPST Form A

● Contact Rating: Initial 100 milliohms maximum

● Contact Life: mech’l: 5 million operations minimum; elect’l: 5 million operations minimum at full load

● Operating Time: 2 milliseconds maximum

● Release Time: 1 milliseconds maximum

● Regulatory Approvals: UL and CSA

When enabled by software, interrupts are generated when digital inputs change state.

+5VDC @ @ 0.750 A (all relays ON) for PCI-IIRO-16

● Ambient PCI-IIRO-16 Temperature: Operating: 0 to +70°C Optional Industrial Version Operating: -30 to +70°C

● Storage: -40 to +85°C

● Humidity: 0 to 90 percent (non-condensing)

● Weight: Approx. 12 oz. (340 grams)

● Size: PCI-IIRO-16 is 6.8″ (173mm) long

● This product is designed to be in full compliance with CE requirements.
