● PCI Express

● I/O connection: VHDCI 68 pin SCSI connector

● Serial ports: 8 RS-232 ports

● Serial data rates: 460.8k baud (up to 921.6k baud) asynchronous

● UART: Octal type 16C950 with 128-byte transmit & receive FIFO, 16C550 compliant

● ESD Protection: ±15kV on all signal pins

● Character length: 5, 6, 7, or 8 bits

● Parity: Even, Odd, None, Space, Mark

● Stop interval: 1, 1.5, or 2 bits

● Flow Control: RTS/CTS and/or DSR/DTR, Xon/Xoff

● Cable: 3′ shielded breakout cable terminated with 8 male D-sub 9-pin connectors

● Operating Temperature 0° to +70°C

● Storage Temperature -40° to +105°C

● Humidity 5% to 95% RH, without condensation

● +3.3VDC @ 0.9W (typical)

● Board Dimension: 4.72″ (120mm) long by 2.20″ (55.8mm) high
