● VCCIO 5V (TTL) or 3.3V (LVTTL)

● Logic High 2.0V to VCCIO

● Logic Low 0V to 0.8V

● Current ±20uA (max)

● Logic High 2.0V (min); 32mA source

● Logic Low 0.55V (max); 64mA sink

● Power Output VCCIO Via 0.5A resettable fuse

● Operating Temperature 0° to +70°C

● Storage Temperature -40° to +105°C

● Humidity 5% to 95% RH, without condensation

● Card Dimensions: 6.62″ long by 4.2″ high (seated)

● I/O Connector TE Receptacle Assy, .050 Series, Amplimite P/N 1761028-4

● This product is designed to be in full compliance with CE requirements.
