● 48 or 24 channel high-current TTL digital I/O lines

● Change of State (COS) detection and interrupt capabilities

● Compatible with industry standard 8255 PPI

● 68-pin SCSI pin-in-socket female connector on card mounting bracket

● User interrupt pin

● All 48 digital I/O lines buffered with 32mA source / 64mA sink

● Four and eight bit ports independently selectable for inputs or outputs

● Jumper configurable pull-ups/-downs on DIO lines

● 5V or 3.3V VCCIO configurable by jumper selection

● Poly-fused VCCIO available to the user on each I/O header

● Easy upgrade from PCI-DIO-48JPLS Family devices

● FACTORY OPTIONS:

- Non-latching connector

- Card without Change-of-State IRQ feature

- RoHS compliant version

- Extended temperature operation (-40°C to +85°C)

- Support for Wind River VxWorks (call for ordering information)

● Process Monitoring

● Manufacturing/Production Test

● Machine Control

● Monitoring and Control

● Security Systems, Energy Management

● Industrial Automation

● Factory Automation

● Laboratory Automation

● Embedded OEM

Available accessories include ribbon cables and shielded round-wire molded cable assemblies. Screw terminal boards and DIN-rail mounts are also available for a variety of quick and easy connectivity options.

The card is supported for use in most operating systems and includes a free Linux and Windows compatible software package. This package contains sample programs and source code in Visual Basic, Delphi, and Visual C++ for Windows. Also provided is a graphical setup program in Windows. Linux support includes installation files and basic samples for programming from user level via an open source kernel driver. Third party support includes a Windows standard DLL interface usable from the most popular application programs. Embedded OS support includes the family of Windows Operating Systems including IoT. ACCES is also now offering a VxWorks driver/library for the ultimate real-time process monitoring and control solution.
