● Number of Outputs: 8 channels

● Type of Outputs: Single-ended or differential

● Resolution: 12-bit resolution

● Unipolar Ranges: 0-2.5V, 0-5V, 0-10V

● Bipolar Ranges: ±2.5V, ±5V, ±10V

● Output Current: 6mA per channel

● Conversion Rate: buffered / non-streaming: 125K Samples per second x 8 channels.

● Conversion Rate: streaming: 400K samples per second TOTAL (ex: 25k Samples per second for 8 channels)

● Relative Accuracy: ±2 LSB typical

● Differential Non-linearity: ±0.2 LSB typical

● Settling Time: 8us typical, 10us max.

● Operating Temp.: 0° to 70°C

● Storage Temp.: -40° to +85°C

● Humidity: 5% to 95% non-condensing

● Board Dimension: 3.550 x 3.775 inches

● Box Dimension: 4 x 4 x 1.25 inches

● Power supplied via USB cable, or by an optional +5VDC regulated AC/DC power supply

● +5VDC @ ~200mA, typical (no load)

● ±12VDC supplied from +5VDC through DC/DC Converters
