● High-speed USB 2.0 device

● Up to 125K conversions per DAC per second

● Streaming waveform data at over 400,000 DAC outputs per second total

● 128K Sample buffer on-board, or Infinitely long streaming waveforms!

● Buffered waveforms at up to 1 million DAC conversions per second total

● ILDA compatible

● Small, portable 8-channel, 12-bit, digital to analog outputs

● Double-buffered allowing simultaneous update of all DACs

● Analog output ranges of 0-2.5V, 0-5V, 0-10V, ±2.5V, ±5V, ±10V

● Single-ended and differential outputs on separate connectors

● PC/104 module size and mounting compatibility

● Rugged small-sized (4″ x 4″ x 1.25″) steel enclosure

● Type B USB connector features industrial strength and high-retention design

● Factory Options:

- Resistors in series with differential connector for impedance matching

- DIN rail mounting provision

- Economy ‘E’ version available without screw terminal board

- OEM (board only) version with PC/104 mounting holes and PCB footprint for added flexibility in embedded applications

- RoHS Available. Please contact us for ordering information

- Support for Wind River VxWorks (call for ordering information)r

● Portable

● Laptop

● Education

● Laboratory

● Industrial Automation

● Embedded OEM
