● Tru-Iso

- IPC-221B

- Port-to-PC: 1500V peak (AC or DC)

- Port-to-port: 500V peak (AC or DC)

Careful attention has been paid to isolation design, including extensive keep-out zones and hand-routed circuit paths, as well as component and material selection.

● Operating Temperature 0° to +70°C, optional -40° to +85°C

● Storage Temperature -40° to +105°C

● Humidity 5% to 95% RH, without condensation

● Power required:+3.3VDC @ 0.25W (mPCIe-UCAN2-ISO: +3.3VDC @ 0.5W)

mPCIe card characteristics

● Weight:5.4 grams (mPCIe-UCAN2-ISO: 6.2 grams)

● Size: Length: 50.95mm (2.006″); Width: 30.00mm (1.181″)

● I/O connector:

- On-card: Molex 2023960307 3-pin Pico-Clasp

- Mating (On-cable): Molex 5013300300

● This product is designed to be in full compliance with CE requirements.
